- Size: 6
- Place of Origin: China
- Brand Name: XinMingTao
- Model Number: RCGF12-12-4
- Weight: 1000.000 kg
---Description
1. Fully automatic rinsing, filling and rotary capping combined machine. Whose main technique was imported from
2. It can apply to fill hot frult juice. Tea and other beveerage into thermal proof PET bottle by changing few parts.
3. The complete set of machine is more advanced in technique, smaller in space occupied, more compact in structure.
4. It is suitable for normal temperature filling or hot filling PET bottled no gas contained beverages (Mineral water, purified water, distilled water, fruit juie, tea and so on).
5. As well as washing, filling and sealing other liquid, such as vinegar, It achieves 1990"s international advanced level, It is the best choice of taking place of imported one.
---Working principle
When bottles are sent to the machine by conveyor continuously, they firstly are deliveried to the receiving wheel by air-slide conveyor and then to washing part. The bottle clamps hold the bottles and trun over 180°to wash, then return back to their original position after enough washing and drying. Then, the bottles are sent to the middle thumb wheel 1 and to the filling part to be filled, then moved by middle thumb wheel 2 and reach to capping part to be capped, at the same time, cap trimmer sends caps to the top of the bottles and capper screws caps. At last, bottles are sent to the conveyor chain by the out stirring wheel to next working position.
---Main Features
1) Automatic tea beverage filling plant has compact structure, complete control system, easy operation and high degree automation.
2) To change bottle shape, its only need replace star-wheel, inlet bottle screw and arc guide plate.
3) Aseptic bottle filling machine applies high speed filling valve, the liquid has precise level and no waste. That guarantees the demand of filling technology.
4) The capping head applies constant magnetic torque device to secure capping quality and wont damage bottle cap.
5) Direct Manufacturer!!! juice bottling machine price applies high effect cap arranging system that has complete self control and protective device.
6) Direct Manufacturer!!! juice bottling machine price is equipped with complete overload protection device that can secure equipment and operator effectively.
7) The control system has the function of control producing speed, cap shortage detection, bottle block auto stop and production counting etc.
- Size: 6
- Place of Origin: China
- Brand Name: XinMingTao
- Model Number: RCGF12-12-4
- Weight: 1000.000 kg
---Main electric brand
Touch screen | Weinview or Siemens |
PLC program controller | Mitsubishi or Siemens |
Inverter | Mitsubishi or Siemens |
Photoelectrical controller | Omron or Autonics |
Proximity switch | Omron |
Other electrical components | Schneider |
Pneumatic component | Airtac or SMC or Festo |
Water pump | CNP or Grundfos |
Main motor | SL or ABB or SEW |
Bearing | Harbin or Igus |
---Technical parameter
Model | RCGF12/12/4 | RCGF18/18/6 | RCGF24/24/8 | RCGF32/32/10 | RCGF40/40/12 |
Capacity(500/ml/bottle/h) | 3000-4000 | 5000-6000 | 8000-10000 | 12000-14000 | 16000-18000 |
Suitable bottle shape | glass circular or square | ||||
Bottle diameter(mm) | Φ 50- Φ 90 | ||||
Bottle height(mm) | 150-310 | ||||
Compressed air pressure(MPa) | 0.3-0.7 | ||||
Washing medium | aseptic water | ||||
Washing water's pressure(MPa) | 0.25 | ||||
Total Power(KW) | 4.4 | 4.4 | 5.2 | 6.2 | 7.8 |
Overall dimensions(mm) | 2230*1630*2250 | 2360*1830*2250 | 2900*2200*2250 | 3880*2200*2250 | 3700*3000*2350 |
Weight (kg) | 2200 | 2500 | 4200 | 6000 | 7000 |
